Tripp Lite, UPS, 600VA, 120V, 300W, Desktop, Compact, 8 x 5-15R Outlets, USB Port, RJ11
Compact desktop UPS with silent alarm provides battery backup support for your home/office network system or digital signage components.
- UPC Code: 037332211033
- UPS Type: Standby
- Input Phase: Single-Phase
- Rated input current (Maximum Load): 6A
- Nominal Input Voltage(s) Supported: 120V AC
- UPS Input Connection Type: 5-15P
- Input Circuit Breakers: 7A
- UPS Input Cord Length (ft.): 5
- Recommended Electrical Service: 15A 120V
- Output Capacity (VA): 600
- Output Capacity (kVA): 0.6
- Output Capacity (Watts): 325
- Output Capacity (kW): 0.325
- Nominal Voltage Details: 120v nominal output in battery mode
- Frequency Compatibility: 50 / 60 Hz
- Output Voltage Regulation (Line Mode): 120V (?20%)
- Output Voltage Regulation (Battery Mode): 120V (?10%)
- UPS Output Receptacles (Surge Suppression Only): 5 UPS outlets, 5 surge-only outlets
- Output AC Waveform (AC Mode): Pure sine wave
- Output AC Waveform (Battery Mode): PWM sine wave
- Nominal Output Voltage(s) Supported: 110V; 115V; 120V
- Output Receptacles: (10) 5-15R
- Battery Type: Valve Regulated Lead Acid (VRLA)
- Runtime Full Load (min.): 1.2 min. (325W)
- Runtime Half Load (min.): 4.5 min. (163W)
- DC System Voltage (VDC): 12
- Battery Recharge Rate (Included Batteries): 6.5 hours (10% to 90%)
- Battery Access: Battery access door
- Internal UPS Replacement Battery Cartridge: IMPORTANT BATTERY REPLACEMENT INFORMATION > If your INTERNET550U has no battery access door, please contact a local electronics repair technician to source and install a matching replacement battery; If your INTERNET550U UPS does have a battery replacement door and the original battery inside has a rating of 12V 3.6AH, please order Tripp Lite replacement battery Model Number RBC36H
- Battery Replacement Description: Replaceable internal batteries (see manual)
- Switches: Switch controls power off/on status
- Audible Alarm: UPS remains silent in battery backup mode; Alarm sounds only to report low-battery, fault, overload and replace-battery conditions
- LED Indicators: 1 Status LED reports operating mode and fault status
- UPS AC Suppression Joule Rating: 316
- UPS AC Suppression Response Time: Instantaneous
- UPS Dataline Suppression: 1 line TEL/DSL or Ethernet
- EMI / RFI AC Noise Suppression: Yes
- Primary Form Factor: Desktop
- Installation Form Factors Supported with Included Accessories: Tower; Ultra-compact desktop; Wallmount
- Primary UPS Depth (mm): 185
- Primary UPS Height (mm): 105
- Primary UPS Width (mm): 110
- Shipping Dimensions (hwd / in.): 7.36 x 5.67 x 10.86
- Shipping Weight (lbs.): 4.92
- UPS Housing Material: ABS
- UPS Power Module Dimensions (hwd, in.): 4.13 x 4.33 x 7.28
- UPS Power Module Weight (kg): 1.80
- UPS Power Module Weight (lbs.): 3.96
- Unit Dimensions (hwd / in.): 4.130 x 4.330 x 7.280
- Unit Weight (lbs.): 4.920
- Operating Temperature Range: 32? to 104?F (0? to 40?C)
- Storage Temperature Range: 5? to 113?F (-15? to 45?C )
- Relative Humidity: 0 to 90%, non-condensing
- AC Mode BTU / Hr. (Full Load): 13.1
- AC Mode Efficiency Rating (100% Load): >98%
- Operating Elevation (ft.): Up to 10,000 ft.
- Operating Elevation (m): Up to 3000m
- PowerAlert Software: For local monitoring via the UPS's built-in USB port, download PowerAlert software at https://tripplite.eaton.com/products/power-alert
- Communications Cable: USB interface cable included
- WatchDog Compatibility: Supports Watchdog application, OS and hard-reboot restart options for remote applications
- Network Management Card DescriptionNetwork management not supported
- Communications Interface: USB (HID enabled)
- Transfer Time: 6 milliseconds typical (10 milliseconds max)
- Low Voltage Transfer to Battery Power (Setpoint): 95
- High Voltage Transfer to Battery Power (Setpoint): 145
- Cold Start (Startup in Battery Mode During a Power Failure): Cold-start operation supported
- High Availability UPS Features: Surge/noise protection
- Green Energy-Saving Features: Greater than 95% efficiency - GREEN UPS
- UPS Applications: Computer/Peripherals; Retail/Point of Sale; Hospitality
- Product Certifications: RETIE (Colombia); CSA (Canada); NOM (Mexico); UL 1778
- Product Compliance: RoHS; FCC Part 15 Class B (USA)
- Product Warranty Period (U.S. & Canada): 3-year limited warranty
- Connected Equipment Insurance (U.S., Canada & Puerto Rico): $100,000 Ultimate Lifetime Insurance
